Horizontal Hot Press Formation Machine for Pouch Cell
Brief Introduction
STC-BHF-8C is a 8 channels hot press forming machine for same-side tab batteries. The equipment adopts horizontal structure, with 1 group of pressurized structure and 4 pressing plates per pressurized structure. Each layer of pressing plate can be used for 2 batteries, total of 8 channels. The equipment is mainly used for pouch lithium-ion batteries to be formation under hot-pressing condition. It can not only combine the existing battery formation process, drying and shaping process, but also shorten the formation time, reduce the battery production cycle and reduce labor. It enables the battery to complete the formation and hot press shaping, and also makes the surface after pumping and sealing more flatter and more beautiful in appearance.
Technical Parameters
| Model | STC-BHF-8C |
| Power supply | AC 220V±10%, single phase |
| Total power | 3KW |
| Compressed air | 0.25～0.76MPa |
| Ambient temperature | 25±15℃ |
| Relative humidity | 30%～75% |
| Dimension | L1130 * W630 * H800mm |
| Weight | 200kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer ?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R& D department.
2. Do you accept customized product ?
A : Yes. Most of our products can be customzied to meet different requirements.
3. Will you provide test video before dispatch ?
A : Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service ?
A : Yes, we can dispatch professional engineer for on-site installation service.
